Xpeedic IRIS provides high frequency silicon design engineer a 3D fast EM simulation tool integrated in Cadence Virtuoso design flow to analyze on-chip passive devices IC designers now have an automated way to access EM analysis of passive devices withou

iModeler allows PDK engineers to stay inside Cadence Virtuoso to create the layout and run EM simulation The built-in fast 3D full-wave solver yields both accuracy and efficiency for PDK models

PDK model quality is essential for designers to design ICs with confidence Typically PDK models are in the form of parameterized formula as function of physical parameters of the device
